Hi Travis.  The MNTC in Louisville offers anodic bonding, but we are not as skilled in wafer thinning.

http://louisville.edu/micronano/
[http://louisville.edu/micronano/files/images/photos/slide6]<http://louisville.edu/micronano/>
Welcome to the MNTC - We are open! — Micro/Nano Technology Center<http://louisville.edu/micronano/>
The Micro/Nano Technology Center (MNTC) is a class 100/1000 $30 million 10,000 ft 2 cleanroom facility and the Huson Imaging & Characterization Laboratory.
louisville.edu

Cheers!


Julia Aebersold, Ph.D.

Manager, Micro/Nano Technology Center

University of Louisville

2210 South Brook Street

Shumaker Research Building, Room 233

Louisville, KY  40292

(502) 852-1572

http://louisville.edu/micronano/<http://louisville.edu/micronano>


________________________________
From: labnetwork-bounces at mtl.mit.edu <labnetwork-bounces at mtl.mit.edu> on behalf of Travis Gabel <travisgabel at boisestate.edu>
Sent: Friday, February 5, 2021 11:34 AM
To: labnetwork at mtl.mit.edu <labnetwork at mtl.mit.edu>
Subject: [labnetwork] wafer bonding and thinning


CAUTION: This email originated from outside of our organization. Do not click links, open attachments, or respond unless you recognize the sender's email address and know the contents are safe.

Hi

We have a project in our lab that requires some wafer to glass bonding. Are there any labs that offer this service or any vendors that you have used for a similar process? We are looking for anodic bonding.

After bonding we need the silicon thinned to ~50um.  Does anyone offer this or have a vendor that they have worked with?

Thanks
Travis
