Hi Sam and Emma,

Sam, thanks for sharing that site, that’s a great resource! Much faster and easier than hunting for every possibility in the online CRC handbook table.

Emma, one other thing that occurred to me: I think you may also want to look at the solubility of the potential compounds. IPA will (obviously) work to dissolve anything soluble in IPA, and more generally provide a wet surface to help the wipe mechanically remove particles or residue, but some compounds are not IPA soluble. For some I looked up, DI H2O may be more appropriate (i.e. not very soluble in alcohol, extremely soluble in water). If you have known contaminant like that, it might make sense to first do DI H2O on a wipe, then IPA. Would be curious to hear from other folks what they do there or think of that. For some other compounds, it might be a bad idea to have water present, I’m not sure.

Thanks,
Justin

From: Sam Azadi <azadi at seas.upenn.edu>
Sent: Wednesday, May 15, 2024 10:22 AM
To: Wirth, Justin C <jcwirth at purdue.edu>
Cc: Emma Anquillare <eanquillare at gc.cuny.edu>; labnetwork at mtl.mit.edu
Subject: Re: [labnetwork] Predicting Solid Etch Products

You don't often get email from azadi at seas.upenn.edu<mailto:azadi at seas.upenn.edu>. Learn why this is important<https://aka.ms/LearnAboutSenderIdentification>
---- External Email: Use caution with attachments, links, or sharing data ----

Hi Emma,

To see what compounds I may have in the chamber, I use the "compounds" section of this link: https://ptable.com/#Compounds
You can just drag and drop the primary elements in the box in the middle, and on the left you'll see a list of all possible and known compounds that have the selected elements. You can start by looking at the boiling point of the ones that may exist inside the chamber, and as Justin said, as a rule of thumb consider the ones with Tbp < 185 C as volatile.

SA

On Wed, May 15, 2024 at 7:53 AM Wirth, Justin C <jcwirth at purdue.edu<mailto:jcwirth at purdue.edu>> wrote:
Hi Emma,

This is a very good question, and one that I’ve struggled to answer as well. I’m not an etch expert but by necessity have had to try to answer some of these questions, and this<https://urldefense.com/v3/__https://purdue.atlassian.net/wiki/spaces/BNCWiki/pages/6246876/Tutorial*on*Etching*TutorialonEtching-GeneralMaterials-Willitetch*3F__;KysjJQ!!IBzWLUs!TANTwddpDwOfbj22F_YUpJEtqvljiVHzw7Z1iLBNvvrYiTz08eoNY0T9ifutauC6eyGzMMW23dZa00RKLcLjUQ$> (reproduced below, not sure if it will come through or not) is a very rough starting point I’ve come up with that I think (hope) helps get in the ballpark. Would love to hear from other folks as to how they approach this.

Materials can generally be etched in the RIEs as long as they form volatile byproducts, or products for which the vapor pressure (at the temperature of the etch) is higher than the pressure of the chamber.

Etching is very complicated and this will be massive oversimplification...but generally volatile byproducts can be determined from literature, or as a fallback, the CRC Handbook of Chemistry and Physics Online, (4) Properties of the Elements & Inorganics, Physical Constants of Inorganic Compounds: https://hbcp.chemnetbase.com/faces/documents/04_02/04_02_0001.xhtml<https://urldefense.com/v3/__https://hbcp.chemnetbase.com/faces/documents/04_02/04_02_0001.xhtml__;!!IBzWLUs!TANTwddpDwOfbj22F_YUpJEtqvljiVHzw7Z1iLBNvvrYiTz08eoNY0T9ifutauC6eyGzMMW23dZa00S9rICseA$>. From there, click "Go to Interactive Table", and find products that may be formed (i.e. chloride, fluorides, oxides, depending on the gasses). A compound is deemed volatile if it has a boiling point at a reasonable temperature range for the temperature and pressure of the system. Note that at lower pressures, boiling points decrease, so these are just a good starting point reference.

As a VERY general rule of thumb, anything with a boiling point (tbp) < 185 C will be volatile in the ICP RIEs.

As an example, aluminum chloride is volatile, and aluminum fluoride and aluminum are not.
[cid:image001.png at 01DAA6B3.729FE810]
[cid:image002.png at 01DAA6B3.729FE810]
[cid:image003.png at 01DAA6B3.729FE810]
[cid:image004.png at 01DAA6B3.729FE810]

Neither Copper chloride or copper fluoride is volatile, which is why it is not allowed in any chamber:
[cid:image005.png at 01DAA6B3.729FE810]
[cid:image006.png at 01DAA6B3.729FE810]
[cid:image007.png at 01DAA6B3.729FE810]
[cid:image008.png at 01DAA6B3.729FE810]
[cid:image009.png at 01DAA6B3.729FE810]
[cid:image010.png at 01DAA6B3.729FE810]

Byproducts of silicon are very volatile:
[cid:image011.png at 01DAA6B3.729FE810]
[cid:image012.png at 01DAA6B3.729FE810]

Many times different fluorides/chlorides of the same material will have drastically different boiling points. It's important to research which will be formed in the plasma. Titanium is a good example of this, with TiCl2  and TiCl3 being non-volatile, and TiCl4 being volatile:
[cid:image013.png at 01DAA6B3.729FE810]
[cid:image014.png at 01DAA6B3.729FE810]
[cid:image015.png at 01DAA6B3.729FE810]


Thanks,
Justin

Justin C. Wirth, PhD
Senior Research Engineer – EBL Processes & Nanofab Process Consultation
Birck Nanotechnology Center | Room 2287A
765.494.8203 | jcwirth at purdue.edu<mailto:jcwirth at purdue.edu>
BNCWiki<https://urldefense.com/v3/__https://purdue.atlassian.net/wiki/spaces/BNCWiki__;!!IBzWLUs!TANTwddpDwOfbj22F_YUpJEtqvljiVHzw7Z1iLBNvvrYiTz08eoNY0T9ifutauC6eyGzMMW23dZa00SOT9T6ag$> | Purdue iLab<https://urldefense.com/v3/__https://purdue.ilabsolutions.com/__;!!IBzWLUs!TANTwddpDwOfbj22F_YUpJEtqvljiVHzw7Z1iLBNvvrYiTz08eoNY0T9ifutauC6eyGzMMW23dZa00T7I8wVQg$> | Book time on my calendar<https://urldefense.com/v3/__https://outlook.office.com/bookwithme/user/5ad94572a9c04a4e8aa9159479128868@purdue.edu?anonymous&ep=plink__;!!IBzWLUs!TANTwddpDwOfbj22F_YUpJEtqvljiVHzw7Z1iLBNvvrYiTz08eoNY0T9ifutauC6eyGzMMW23dZa00Tyx7nbGQ$>

From: labnetwork <labnetwork-bounces at mtl.mit.edu<mailto:labnetwork-bounces at mtl.mit.edu>> On Behalf Of Emma Anquillare
Sent: Friday, May 10, 2024 12:07 PM
To: labnetwork at mtl.mit.edu<mailto:labnetwork at mtl.mit.edu>
Subject: [labnetwork] Predicting Solid Etch Products

You don't often get email from eanquillare at gc.cuny.edu<mailto:eanquillare at gc.cuny.edu>. Learn why this is important<https://urldefense.com/v3/__https://aka.ms/LearnAboutSenderIdentification__;!!IBzWLUs!TANTwddpDwOfbj22F_YUpJEtqvljiVHzw7Z1iLBNvvrYiTz08eoNY0T9ifutauC6eyGzMMW23dZa00RjgrJ9kQ$>
---- External Email: Use caution with attachments, links, or sharing data ----


Dear Lab network,



First time caller here 😊



I am new to plasma etching, and working to institute better process control in our ICP and RIE etchers in an academic shared use facility. We don’t have the capacity to designate a single etcher for each process, so between our three tools, we essentially have a most-restricted, somewhat restricted, and “dirty” tool. To avoid cross contamination and chamber residue buildup, we have a technician manually scrub out the chambers with IPA every week- usually seeing the most solid residue in our ICP that handles Lithium Niobate milling.



My question is- while many products of etch reactions get pumped away as vapors, what about the reactions that do leave solid residues? Is there a systematic way to predict or look up what solids will be left from common (or unusual) reactions, and know how they will react and interact with other solids and gasses present in your chamber? Especially with such frequent manual cleaning, how do you ensure that you don’t inadvertently open the chamber to something acutely toxic, pyrophoric, shock sensitive, etc?



Very curious to learn what steps people take and tools they use (literature? calculations? databases? forums?)  when approaching this problem, and when asked to allow a new material into a tool.



Best,

Emma
